How to Use LLM Orchestration

This guide covers the AI-assisted workflow for analyzing experiments.

Overview

LLM Orchestration is available in API-enhanced mode (requires Anthropic API key). The system analyzes the experiment and recommends processing strategies for each document.

Prerequisites

  • Anthropic API key configured in Settings
  • An experiment with associated documents
  • Documents should have text content extracted

The 5-Stage Workflow

LLM Orchestration follows a structured workflow with human review at each decision point:

Stage 1: Analyze

The LLM examines the experiment to understand:

  • Research goals and scope
  • Document characteristics (length, format, historical period)
  • Focus terms and their domains
  • Temporal range of the corpus

Stage 2: Recommend

Based on the analysis, the system recommends:

  • Which tools to apply to each document
  • Processing order and dependencies
  • Confidence scores for each recommendation
  • Rationale explaining the choices

Example recommendations:

Document Recommended Tools Confidence
Historical paper (1910) Entity extraction, Definition extraction 0.92
Modern technical paper Semantic segmentation, Entity extraction 0.88
Legal dictionary entry Definition extraction, Temporal extraction 0.95

Stage 3: Review

Recommendations are reviewed before execution:

  • Approve recommendations as-is
  • Modify tool selections for specific documents
  • Add processing notes
  • Reject and request re-analysis

All LLM recommendations require human approval before execution.

Orchestration Review

Stage 4: Execute

After approval, the system processes documents:

  • Tools run using local NLP libraries (spaCy, NLTK, sentence-transformers)
  • Progress tracked in real-time
  • Results stored as ProcessingArtifacts with PROV-O provenance

Available Processing Tools:

  • Entity Extraction (spaCy): Named entities (PERSON, ORG, GPE) + noun phrase concepts
  • Temporal Extraction (spaCy + regex): Dates, periods, historical markers, relative expressions
  • Definition Extraction (pattern matching):
  • Pattern matching for 8 definition types (explicit, copula, acronym, appositive, etc.)
  • Strict acronym validation requiring first-letter matching
  • Quality filters to reject citations, reference lists, and nonsense patterns
  • Text Segmentation: Structure-aware document splitting
  • Embedding Generation (sentence-transformers): Period-aware semantic vectors
  • LLM Text Cleanup (Claude): Modernize OCR errors while preserving historical terminology

Stage 5: Synthesize

The LLM analyzes results across all documents:

  • Identifies patterns and themes
  • Generates term cards with frequency data
  • Organizes findings by temporal period
  • Does not interpret results - preserves researcher authority

Accessing LLM Orchestration

  1. Go to Experiments and select an experiment
  2. Click Document Pipeline
  3. Select LLM mode (toggle at top of page)
  4. Click LLM Analyze to begin Stage 1

Workflow States

State Description
not_started Orchestration not yet initiated
analyzing Stage 1 in progress
awaiting_approval Recommendations ready for review
executing Processing documents
synthesizing Generating cross-document insights
completed All stages finished
error Processing encountered an error

Manual Alternative

To process documents without LLM orchestration:

  1. Go to Document Pipeline in the experiment
  2. Select documents manually
  3. Choose processing operations
  4. Click Run Selected Tools

Manual selections are recorded with the same PROV-O provenance structure.

When to Use LLM Orchestration

  • Large document collections (10+ documents)
  • Mixed document types requiring different tools
  • For AI-generated synthesis of patterns across documents

When to Process Manually

  • Small experiments (< 5 documents)
  • When specific tools are already determined
  • When API costs are a concern

Troubleshooting

Orchestration stuck

  • Check that Celery worker is running
  • Verify API key is valid and has quota
  • Review application logs for errors

Recommendations seem wrong

  • Ensure documents have metadata (especially publication date)
  • Check that document text was extracted correctly
  • Try providing more specific experiment description
